Profit Bands Across A Paddock
Justin Pishief and Dan Bloomer
Centre for Land and Water
As part of the Onions NZ project “Benchmarking Variability in Onion Crops” a process was developed to generate yield and profit maps. This presentation explains the process using the example of a 7.3 ha paddock in Hawke’s Bay.
Data from a satellite image captured in late November were used to identify high, medium and low biomass zones. Paddock yield samples were taken from these zones at harvest and used to generate a paddock yield map. The average yield of the paddock was estimated at 95 t/ha, with a predicted total field harvest of 669 tonnes. This compares to the grower recorded harvest of 614 tonnes.
The relative yield data were combined with grower supplied costs and returns to determine gross margins across the paddock. Data were mapped in ArcGIS and a Gross Margin map with five “profit bands” produced. The highest band had a mean Gross Margin of $11,884/ha compared to the lowest at $3,225/ha.
The breakeven gross margin yield is estimated to be 62.5 t/ha at current costs and prices. The estimated cost to business of low performing areas is $27,945, assuming the whole paddock could achieve the top band mean yield.
The poorest performing areas were identified by the grower as impacted by a failed council drain and areas of slowed drainage in the main paddock areas. An OptiSurface® assessment using historic HBRC LiDAR elevation data analysed of the impact of ponding on the site and also suggested ponding was a significant issue.
An OptiSurface® landform assessment was conducted using both single plain and optimised surface designs and the soil movement required to allow effective surface drainage was determined.
The assessment showed ponding could be avoided by land shaping with 224 m3/ha soil movement and few areas requiring more than 100 mm cut or fill. The cost is estimated at $2,000/ha or approximately $14,000 total.
